Package Size 18.00cm * 20.00cm * 5.00cm Package Gross Weight 1.000kg Water Fountain Solenoid Valve Underwater Cu Alloy V

Send your inquiry

DESCRIPTION

Basic Info.
Model NO. 2W-500-50
Usage Air transport Screwdriver, Impact Wrench, Air Drill, Grinding Machinery, Air Compressor, Air Line
Brand Anruk
Work Temperature Normal Temperature
Material Stainless Steel
Pressure 0~1.0MPa
Coil Voltage DC12~24V (±10%), AC110~220V, 50/60Hz
Media Water, Air, Gas, Oil, Liquid
Power Solenoid
Transport Package Carton
Specification 2 in
Trademark ANRUK
Origin China
HS Code 8481804090
Production Capacity 50000PCS/Month
Packaging & Delivery
Package Size 18.00cm * 20.00cm * 5.00cm Package Gross Weight 1.000kg
Product Description

Water Fountain Solenoid Valve Underwater Cu Alloy Valve Body

2W-500-50 Water Fountain Solenoid Valve Underwater Cu Alloy Valve Body


2W-500-50 Water Fountain Solenoid Valve Underwater Cu Alloy Valve Body


Basic Information
Model NO.2W-500-50Power SupplyAC Solenoid Valve
Usage
Flow Control
Standard
GB
Application
Water Industrial Usage
Certification
ISO, CE
Thread
G,PT,NPT,BSPP
Port Size
1/8"~2"
QualityHigh
Price
Low
ServiceGood
Trademark
ANRUK
Transport PackagePlastic Bag & CartonSpecification
CE, ISO
Origin
China
HS Code8481804090

Specifications:It is direct action type two-position two-way solenoid valve.It adopts the diaphragm seal structure,with zero differential pressure starting function,handsome shape,and large flow.It is a switch element most normally used in modern industrial pipeline.
Model 2W-500-50
Working Medium Air, Water, Oil, Gas
Operation Direct Acting
Acting Type Normally Closed
Orifice Size(mm) 20
CV Value 4.8
Port Size 2in
Port Size 2in
Operation Fluid Viscosity 20 CST Below
Operating Pressure Air:0~1.0Mpa, Water:0~0.7Mpa, Oil:0.9Mpa
Max. Pressure Resistance 1.0Mpa
Operating Temperature NBR for -5 ~80°C
Voltage Range ±10%
Material of Body Brass
Material of Oil Seal NBR


About AngRui
1.Since 2010. About 10 years of manufacturing and export.2.Main products:Solenoid Valve, Pneumatic Fitting, PU Tube, Hydraulic Cylinder.3. Main markets: America, Europe, Brazil and so on.4.We accept Western Union, T.T, L/C payment.5. Expert packing to protect products in shipment.6. OEM is acceptable.7. Sample order is acceptable8. Fast responsible to all your questions.9. 100% quality test before packing. Short delivery time for standard products.
